Spindle speed: 9000 rpm
Guide Rail Width: 80 mm
Premilling Motor: 7.5kw x 4
Grooving Motor: 5.5kw x 1
Ends Trimming Motor: 0.5kw x 2
Rough Trimming Motor: 0.75kw x 2
Reducer Power: 5.5kw
Edge Thickness: 0.4-0.7mm
Edge Width: 10-120mm
Panel Thickness: 40-60mm
Min Panel Width: 120mm
Min Panel Length: 200mm
Conveyor Power: 5.5kw
Overall Dimension: 8650x1000x1950mm
Weight: 2750 kg
Voltage: 380V 50hz 3ph
Dust Outlet Dia.: 100 mm
Air Pressure: 0.5-0.7MPa
